Fishing Net Raschel Machines
Type: WMF
Fishing Net Raschel Machines
Support & Help
If you need more help, please contact us by the inquiry form.

Equipped with 1 latch needle bar. 6 ground guide bars (set 1 in - 1 out), 2 pattern guide bars (for selvedge), 1 knockover comb bar, 1 sitch com bar


Provided for 6 yarn beams with 17” - 30” flange diameter. With electronic beam auto feeding system or machanical let-off system.
4 roller fabric take-up with change gear box or servo motor drive. Separate batching device with its own drive for taking up a fabric roll of up to 40” = 1016 mm dia.
    Model
    WMF
  • Applicable Yarn
    HDPE monofilaments, polyester, nylon.
  • Working Width
    75" - 260".
  • Gauges
    6 - 18 needle per inch.
  • Warp Supply System
    From: Warping beams.
  • Performance
    350 - 400 RPM.
  • Number of Bars
    8 ground bars.
  • Main Motor
    4 kw - 7.5 kw.
  • Machine Weight
    6,000 kgs - 9,500 kgs.
Drive of the knitting elements by combined crank and special cam, which are dynamically balanced and run in oil in the machine bed. Inching drive for easier run-in and for control of knitting element.
Infinitely variable AC-motor.
Electronic guide bar system or pattern chain link system
