Bale Wrap Net Raschel Machine
Type: WMH-210GF-3EL / Raschel Warp knitting Machine
Our Bale Wrap Net Raschel Machine is the perfect solution for businesses that need to produce high-quality, high-speed bale and pallet warp nets for packaging and transporting.
With a working width of 210 inches and gauges of E6/6 (1 needle per 25.4mm), this machine can produce a variety of nets for different purposes.
This machine is equipped with user-friendly control panel and an automatic yarn tensioning system. It also has a high-speed warp supply system that ensures that your nets are produced quickly and efficiently.
Bale Wrap Net Raschel Machine
-
The machine working width 210 inches(5334mm)
- Machine gauges: E6/6(1 needle per 25.4mm)
- Knitting elements: single needle bar, knock-over comb bar and 3 ground bars.
- Pattern drive: Electronic guide bar motion control system.
- Fabric take-up: 4 roller system driven by geared motor controlled by motion control.
- Yarn feeding from slitting extension device driven by servo control system machine.
- Main application: producing bale and pallet warp nets for packaging and transporting.
-
Applicable YarnHDPE Flat Yarn
-
Working Width210"
-
Machine Gauges1 needle per inch
-
Warp Supply SystemFrom: Slitting Extrusion Machine
-
Performance500 - 600 RPM
-
Number of Bars2 - 3 Bars
-
Main Motor7.5 kw
-
Machine Weight8000 kgs
-
Model
WMH-210GF-3EL
